Monitor up to 16 SDI sources using an Ultra HD monitor or television so you get twice the resolution per view! Monitor from SD, HD or Ultra HD-SDI sources in any combination, in any order! Features full frame re-sync on each input.

Advanced SSD dock with 4 separate SSDs that can be accessed via a single high speed 10 Gb/s USB-C connection. Specifically designed for the film and television industry, Blackmagic MultiDock 10G features a rack mount design with an independent SATA driver chip on each disk to ensure fast data transfer speeds. Can be connected directly to computers for editing directly from media disks and also used with HyperDeck Extreme 8K HDR for recording and playback.

The Blackmagic Duplicator 4K is like two recorders in one! Featuring an advanced 12G-SDI design, 25 SD card recorders, and built in hardware encoders for H.264 and H.265, the Blackmagic Duplicator 4K can be used for either live duplication or long form recording. When used as a duplicator, it can simultaneously encode and record onto 25 SD cards at at time. When used as a long form recorder, it can record non-stop for weeks at a time. Multiple units can also be chained together for even longer recording times!

Blackmagic Video Assist 7” 3G is a portable monitor, a professional recorder, a portable scope and a fantastic camera viewfinder solution! You can also add better quality record codecs and a larger monitor to any SDI or HDMI camera! The new design has innovations such as 4 built in scopes, enhanced focus assist features, a tally indicator and built in 3D LUTs. The Video Assist 7” 3G support formats up to 1080p60 and the new design also has L-Series batteries for longer life. Blackmagic Video Assist 7” 3G really is 4 products in one!

Blackmagic Video Assist 5” 3G is a portable monitor, a professional recorder, a portable scope and a fantastic camera viewfinder solution! You can also add better quality record codecs and a larger monitor to any SDI or HDMI camera! The new design has innovations such as 4 built in scopes, enhanced focus assist features, a tally indicator and built in 3D LUTs. The Video Assist 5” 3G support formats up to 1080p60 and the new design also has L-Series batteries for longer life. Blackmagic Video Assist 5” 3G really is 4 products in one!

For extreme power, the HyperDeck Studio 4K Pro has all the features of the HD models, combined with incredible processing for working in Ultra HD. This model’s SDI has been upgraded to full 12G-SDI with a loop 12G-SDI output. The two SDI outputs are both 12G-SDI so you can play ProRes 4444 files for true Ultra HD fill and key out. The HDMI connections and the ProRes and DNx file formats all switch between SD, HD and Ultra HD television standards. Like the other models, H.264 is included for SD and HD, but then switches to H.265 when recording in Ultra HD. Even the networking has been upgraded to 10G Ethernet for incredible speed! You also get 2 redundant AC power supplies!

The most compact model of HyperDeck Studio is based on the Teranex Mini form factor. This modular design means that you can use a Teranex Mini Rack Shelf to rack mount 3 HyperDeck Studio HD Minis in a single rack unit, or you can combine them with other products such as switchers, converters or streaming processors. It might be small, but you still get powerful features, such as 3G-SDI in and out, HDMI output, dual SD card media slots, built in sync and timecode generators, front panel controls and both AC and DC power inputs. You can even connect the USB to a computer as HyperDeck Studio HD Mini works like a webcam so you can use any video software!

The HyperDeck Studio HD Pro includes all the features of the Plus model but at a full rack width size, there's space for more features! The larger model has space for two SSD slots but still includes the two SD card slots of the smaller models. This means you can instantly move media cards between different models of HyperDeck Studio. You get the nice transport control buttons as well as a machined metal search dial with electronic clutch for limiting rotation when in shuttle mode. There are also dedicated buttons for jog, shuttle and scroll search dial modes. The rear panel has extra space so the timecode connections have been upgraded to XLR connectors.

HyperDeck Studio HD Plus includes all the features of the Mini model, but is larger so it has more space for extra controls and extra connections. This model adds 6G-SDI so it can record and playback ProRes up to Ultra HD 30fps, and it includes an SDI loop out and HDR support. Plus the two 6G-SDI outputs allow fill and key playback up to 1080p60. There is also an HDMI input and a dedicated 3G-SDI monitoring output with overlays. Any button pushed on the front panel is sent to a dedicated RS-422 remote output and the DC power is now a broadcast style XLR connector. The front panel is also upgraded with better transport control buttons, a headphone socket and built in speaker.

ATEM Television Studio HD is the first production switcher designed for both broadcasters and AV professionals. It includes 4 SDI and 4 HDMI inputs with re-sync on all inputs so you can use it with broadcast or consumer cameras. ATEM Television Studio HD is packed with high end features and is perfect for live production, episodic television programming, web shows, AV or even live coverage of gaming competitions! Simply plug in cameras, game consoles or computers and start switching live Connections Total Video Inputs 8 Total Outputs 8 Total Aux Outputs 1 SDI Rates 270Mb, 1.5G, 3G. Total Audio Inputs 2 x XLR. Total Audio Outputs 1 x Headphone. Timecode Connection None. SDI Video Inputs 4 x 10-bit SD/HD switchable. 2 channel embedded audio. HDMI Video Inputs 4 x HDMI type A, 10-bit SD/HD switchable. 2 channel embedded audio. Reference Inputs Tri-Sync or Black Burst. Video Input Re‑Sync On all 8 inputs. SDI Program Outputs 5 x 10-bit SD/HD switchable. HDMI Program Outputs None. SDI Audio Outputs 2 Ch embedded into SDI output. Total Multi Views 1 SDI Multi View Outputs 1 HDMI Multi View Outputs 1 Computer Outputs None. ATEM Television Studio HD Standards SD Video Standards 525i59.94 NTSC 4:3 or 16:9, 625i50 PAL 4:3 or 16:9 HD Video Standards 720p50, 720p59.94 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p50, 1080p59.94, 1080i50, 1080i59.94 Ultra HD Video Standards None. SDI Compliance SMPTE 259M, 292M and 424M. Video Sampling 4:2:2 10-bit Color Precision 4:2:2 10-bit Color Space 4:2:2 YUV HDMI Input Resolutions for Computers 720 x 480i 59.94Hz, 720 x 576i 50Hz, 1280 x 720p 59.94Hz 50Hz and 1920 x 1080p 23.98, 24, 25, 29.97,30, 50, 59.94 and 1920 x1080i 50 and 59.94Hz 60Hz. Colorspace Conversion Hardware based real time. Processing Delay 6 Lines. Audio Mixer 10 input x 2 channel mixer. Selectable On/Off/Audio-Follow-Video. Level and Peak metering. Master gain control. Headphone output level control with separate mix of Program, Talkback and Sidetone. Product Specifics Upstream Keyers 1 Downstream Keyers 2 Chroma Keyers 1 Linear/Luma Keyers 3 Talkback Support Built in, uses aviation headset. Mix Minus Support Yes, on 4 camera PGM outputs. Transition Keyer (Stinger/DVE) DVE only. Total Number of Layers 5 Pattern Generators 2 Color Generators 2 DVE with 3D Borders & Drop Shadow 1 Interface Minimum monitor resolution of 1366 x 768. Number of Windows 1 x 10 Routable Windows 8 routable and 2 fixed for Program and Preview. Tally Red for program and green for preview indication. Tally Output Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included.) Windows Source Labels Yes Multi View Monitoring Multi View Monitoring 1 x 10 Views. Multi View Video Standard HD Media Player Media Players 2, with non volatile flash memory. Channels Fill and key for each Media Player. Media Pool Still Image Capacity 20 with fill and key. Media Pool Clip Capacity None. Media Player Clip Length in 720 HD None. Media Player Clip Length in 1080 HD None. Media Player Clip Length in Ultra HD None. Media Pool Still Image Format PNG, TGA, BMP, GIF, JPEG and TIFF. Media Pool Video File Format None. Media Pool Audio File Format None. Control Control Panel Built in control panel. Software control panel included. Supports optional broadcast panel. Control Panel Connection Ethernet supports 10/100/1000 BaseT. Allows direct connection between panel and chassis, or via network. Also used for updating the software. Control Panel Compatibilty Includes ATEM Software Control Panel. Also compatible with ATEM 1 M/E Broadcast Panel and ATEM 2 M/E Broadcast Panel. Control Panel Included ATEM Software Control Panel included free for Mac 10.10 Yosemite, Mac 10.11 El Capitan or later and Windows 8.1 64-bit or Windows 10 64‑bit. Software Software Updates Using USB connection directly connected to Mac or Windows computers. Includes ATEM Setup Utility Configuration Set via ATEM Software Control Panel, excluding ATEM chassis IP address which is set via the ATEM Setup Utility connected via USB to chassis. Operating Systems Mac icon Mac 10.14 Mojave, Mac 10.15 Catalina or later. Windows Icon Windows 8.1 or Windows 10. Power Requirements Power Supply 1 x internal 100 – 240V AC Power Usage 40W Physical Specifications ATEM Television Studio HD Environmental Specifications Operating Temperature: 5° C to 40° C (41° ‑ 104°F) Storage Temperature: -10° to 60° C (14° to 140° F) Relative Humidity: 0% to 90% non‑condensing What's Included ATEM Television Studio HD SD card with software and manual

ATEM Television Studio Pro HD is the first production switcher designed for both broadcasters and AV professionals with a fully featured hardware control panel built in. It includes 4 SDI and 4 HDMI inputs with re-sync on all inputs so you can use it with broadcast or consumer cameras. ATEM Television Studio Pro HD is packed with high end features and is perfect for live production, episodic television programming, web shows, AV or even live coverage of gaming competitions! Simply plug in cameras, game consoles or computers and start switching live! Connections Total Video Inputs 8 Total Outputs 8 Total Aux Outputs 1 SDI Rates 270Mb, 1.5G, 3G. Total Audio Inputs 2 x XLR. Total Audio Outputs 1 x Headphone. SDI Video Input 4 x 10-bit SD/HD switchable. 2 channel embedded audio. HDMI Video Inputs 4 x HDMI type A, 10-bit SD/HD switchable. 2 channel embedded audio. Reference Inputs Tri-Sync or Black Burst. Video Input Re‑Sync On all 8 inputs. SDI Program Outputs 5 x 10-bit SD/HD switchable. SDI Audio Outputs 2 Ch embedded into SDI output. Total Multi Views 1 SDI Multi View Outputs 1 HDMI Multi View Outputs 1 ATEM Television Studio Pro HD Standards SD Video Standards 525i59.94 NTSC 4:3 or 16:9, 625i50 PAL 4:3 or 16:9 HD Video Standards 720p50, 720p59.94, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p50, 1080p59.94, 1080i50, 1080i59.94 Ultra HD Video Standards None SDI Compliance SMPTE 259M, 292M and 424M. Video Sampling 4:2:2 10‑bit Color Precision 4:2:2 10‑bit Color Space 4:2:2 YUV HDMI Input Resolutions for Computers 720 x 480i 59.94Hz, 720 x 576i 50Hz, 1280 x 720p 59.94Hz 50Hz and 1920 x 1080p 23.98, 24, 25, 29.97,30, 50, 59.94 and 1920 x1080i 50 and 59.94Hz 60Hz. Colorspace Conversion Hardware based real time. Processing Delay 6 Lines. Audio Mixer 10 input x 2 channel mixer. Selectable On/Off/Audio-Follow-Video per channel plus separate gain control per channel. Level and Peak metering. Master gain control. Headphone output level control with separate mix of Program, Talkback and Sidetone. Product Specifics Upstream Keyers 1 with Chroma/Linear/Luma key. Downstream Keyers 2 Chroma Keyers 1 Linear/Luma Keyers 3 Talkback Support Built in, uses aviation headset. Mix Minus Support Yes, on 4 camera PGM outputs. Transition Keyer (Stinger/DVE) DVE only. Total Number of Layers 5 Pattern Generators 2 Color Generators 2 DVE with 3D Borders & Drop Shadow 1 Interface Minimum monitor resolution of 1366 x 768. Number of Windows 1 x 10 Routable Windows 8 routable and 2 fixed for Program and Preview. Tally Red for program and green for preview indication. Tally Output Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included) Windows Source Labels Yes. Multi View Monitoring 1 x 10 Views. Multi View Video Standard HD Media Player 2, with non volatile flash memory. Channels Fill and key for each Media Player. Media Pool Still Image Capacity 20 with fill and key. Media Pool Still Image Format PNG, TGA, BMP, GIF, JPEG and TIFF. Control Control Panel Built in with camera control. Software panel included. Supports optional broadcast panel. Control Panel Compatibilty Includes ATEM Software Control Panel. Also compatible with ATEM 1 M/E Broadcast Paneland ATEM 2 M/E Broadcast Panel. Control Panel Included ATEM Software Control Panel included free for Mac 10.11 El Capitan, Mac 10.12 Sierra or later and Windows 8.1 64-bit or Windows 10 64‑bit. Software Software Updates Using USB connection directly connected to Mac or Windows computers. Includes ATEM Setup Utility. Configuration Set via ATEM Software Control Panel, excluding ATEM chassis IP address which is set via the ATEM Setup Utility connected via USB to chassis. Operating Systems Mac icon Mac 10.14 Mojave, Mac 10.15 Catalina or later. Windows Icon Windows 8.1 or Windows 10. Power Requirements Power Supply 1 x Internal 100 - 240V AC. 4 pin 12V DC. Power Usage 40W Physical Specifications ATEM Television Studio Pro HD Environmental Specifications Operating Temperature: 5° C to 40° C Storage Temperature: -20° to 60° C (-4° to 140° F) Relative Humidity: 0% to 90% non‑condensing What's Included ATEM Television Studio Pro HD SD card with software and manual

ATEM Television Studio Pro 4K features 8 independent 12G-SDI inputs, for working in all popular HD and Ultra HD formats up to 2160p60. Each input features re-sync as well as a full low latency standards converter, which means the input is automatically adapted to the switchers format. You can even have 8 inputs, all running different video formats! The upgraded Fairlight audio mixer features dynamics, 6 band parametric EQ, dual mono channel split and stereo simulator with audio delay on the analog inputs. ATEM Television Studio Pro 4K also features the ATEM Advanced Chroma Key, Ultra HD multi‑view and motion clips in the media pool.

ATEM Production Studio 4K lets you connect up to 8 SD, HD or Ultra HD 4K video cameras, disk recorders and computers to do true broadcast quality work. You get all the features you expect from a professional switcher including chroma key, transitions, media pool, downstream keyers, audio mixer, multi view and the world's first 6G-SDI and HDMI 4K video connections.

ATEM Mini Pro is fast to set up and easy to use. It includes 4 standards converted HDMI inputs, USB webcam out, HDMI out, Fairlight audio mixer with EQ and dynamics, DVE for picture in picture, transition effects, green screen chroma key, 20 stills media pool for titles and free ATEM Software Control. ATEM Mini Pro also includes direct recording to USB flash disks in H.264 and direct streaming via Ethernet to YouTube Live and more. There's also a multiview with 4 cameras, media, preview and program plus status of recording, streaming and audio.

ATEM Mini features 4 HDMI inputs and has an intuitive, easy to use design that makes it possible for anyone to live stream multi camera productions online via services and software such as YouTube Facebook Live or even Skype. Simply connect 4 high quality HDMI inputs that can be used for live switching cameras, computers or even game consoles. You get a built in DVE for exciting picture in picture effects, broadcast quality transitions, upstream keyers for removing blue and green screen background, a downstream keyer for superimposing custom graphics, audio inputs, a mixer, and more. To stream, ATEM Mini also has a USB output that works like a webcam, so you can connect to any video software. There's also HDMI video out for projectors.

Get one of the world’s most compact and advanced switchers with the new ATEM 4 M/E Broadcast Studio 4K. You get an incredibly high performance live production switcher designed to work with the latest formats and high frame rates, all the way up to Ultra HD 2160p59.94! You get 16 next generation ATEM Advanced Chroma Keyers with 4 per M/E, perfect for advanced work and virtual sets. As the most advanced ATEM switcher, this model also includes the latest technology and features such as 2 Ultra HD multi viewers, full 2D DVE, built in SuperSource compositing engine with 4 picture in picture DVE's, full re-synchronization on each 12G-SDI input and much more! The multi rate 12G-SDI connections automatically switch between all HD and Ultra HD formats up to 2160p59.94 with a single BNC cable! Even if you're not working in Ultra HD now, the ATEM 4 M/E Broadcast Studio 4K has all the power and features for the highest end live production work, while being Ultra HD ready the instant you need it!

The advanced ATEM 1 M/E Production Studio 4K model switches between SD, HD or Ultra HD video standards so you can connect a wide range of video sources such as cameras, disk recorders and computers. Featuring 10 inputs, chroma keys, transitions, media pool, 4 upstream keyers, downstream keyers, audio mixer, multi view, full motion DVE, stinger transitions, large media pool with full motion clips and 3 auxiliary outputs!

The new ATEM 1 M/E Advanced Panel is an elegantly designed professional hardware control panel for all ATEM switchers. It combines modern design with the latest broadcast technology for faster workflows. The new design features a built in LCD and high quality curved buttons that help reduce incorrect key presses. The buttons also have color backlighting to help you quickly recognize important keys. You also get a professional joystick for DVE and camera adjustments, smooth weighted t-bar fader and much more. The buttons feature dynamic displays that allow full customization of the labels as well as custom colors. The shift buttons allow you to double up the number of inputs by selecting a second set of shifted source buttons so you can control up to 20 inputs. The compact size and durable design of the ATEM 1 M/E Advanced Panel fits in a standard equipment rack, making it perfect for shelf mounting in broadcast trucks, mobile racks and fly away kits.

The Blackmagic Camera Fiber Converter lets you extend and power your URSA Broadcast from up to 2 km away using industry standard SMPTE fiber cables. It also includes common live camera controls with multiple channels of talkback and standard television industry talkback headset connections. The Blackmagic Camera Fiber Converter features 1 Ultra HD camera feed, plus 3 HD return feeds in a compact IP video based design.

Blackmagic Audio Monitor 12G gives you fantastic quality audio monitoring in an impossibly small one rack unit size! With a dual subwoofer design combined with extra wide range speakers all backed by a super powerful class D amplifier. Blackmagic Audio Monitor 12G has been designed to be both an audio and video monitoring solution so you get advanced 12G‑SDI up to 60p input, as well as balanced XLR analog audio, balanced AES/EBU digital audio and consumer level HiFi audio inputs. Blackmagic Audio Monitor 12G features an elegant design with big bright multi color VU, PPM or Loudness audio meters and a built in LCD for monitoring video sources. You even get HDMI 4K output so you can connect a television for big screen video monitoring of your SDI sources!

Now you can control Blackmagic Design cameras by inserting control commandsinto the SDI feed from an Arduino!

ATEM Talkback Converter 4K handles up to 8 cameras for SDI talkback using embedded audio channels 15 and 16 as used on the Blackmagic Studio Cameras and ATEM Camera Converter. Supports 12G-SDI for all SD, HD and Ultra HD formats up to 2160p60 and provides BNC connections to each camera, and an optical fiber socket for adding an optical fiber SFP module for extending camera distances when required. Includes push to talk buttons, support for tough and common aviation headsets, loop through for more than 8 camera support, built in speaker, front panel mic input and much more.

Ultra HD live production switcher with so many features, you can combine them all to make an incredibly powerful 8K switcher! This massive 4 M/E switcher features 40 12G-SDI inputs, 24 12G-SDI aux outputs, 4 DVEs, 16 ATEM Advanced Chroma Keyers, 4 media players, 4 independent Ultra HD multi viewers, 2 SuperSource processors and even standards conversion on all inputs! When switched to work in 8K, all of these features are be combined to make a powerful native 8K switcher! You even get built in talkback and a professional 156 channel Fairlight audio mixer with EQ and dynamics! Connections Total Video Inputs 40 x up to Ultra HD / 10 x in 8K Total Video Outputs 28 x up to Ultra HD / 7 x in 8K Total Aux Outputs 24 x up to Ultra HD / 6 x in 8K SDI Rates 1.5G, 3G, 6G, 12G Total Audio Inputs 2 x balanced 1/4 inch Jack, 1 x 32 stereo channel BNC MADI in. Total Audio Outputs 2 x balanced 1/4 inch Jack, 2 x 32 stereo channel BNC MADI out. Timecode Connections None Reference Input Tri-Sync or Black Burst. Video Input Re-sync On all 40 inputs. Frame rate and format converters On all 40 inputs. SDI Video Inputs 40 x 10-bit 720p, 1080i, 1080p, 2160p and 10 x 4320p switchable. Extra Audio Outputs 1 x 5 pin XLR Talkback. SDI Audio Outputs 2 Ch embedded into SDI output on all outputs. Extra Audio Inputs 1 x 5 pin XLR Talkback. SDI Program Outputs Any of the 24 SDI outputs. Down Converted SDI Program Output None SDI Preview Outputs Any of the 24 SDI outputs. Total Multi Views 4 x up to Ultra HD / 1 x in 8K SDI Multi View Outputs 4 HDMI Multi View Outputs None Control Panel Connection Ethernet supports 10/100/1000 BaseT. Allows direct connection between panel and chassis, or via network. Internal Timecode Generator Yes Tally Output Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included). Computer Interface 1 x USB 2.0 port. ATEM Constellation 8K Standards SD Video Standards None HD Video Standards 720p50, 720p59.94 1080i50, 1080i59.94 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p50, 1080p59.94 Ultra HD Video Standards 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p50, 2160p59.94 8K Video Standards 4320p23.98, 4320p24, 4320p25, 4320p29.97, 4320p50, 4320p59.94 SDI Compliance SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M Level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 and SMPTE 2082-10, SMPTE 2082-12. Video Sampling 4:2:2 Color Precision 10-bit. Color Space REC 601, REC 709, REC 2020. SDI Auto Switching Automatically detects between level A and level B 3G-SDI, 6G-SDI and 12G-SDI. Requires 2SI in 8K mode. Product Specifics Upstream Keyers 16 x up to Ultra HD / 4 x in 8K with Chroma/Linear/Luma key. Downstream Keyers 4 x up to Ultra HD / 2 x in 8K. Advanced Chroma Keyers 16 x up to Ultra HD / 4 x in 8K. Talkback Support Yes Mix Minus Support Yes Linear/Luma Keyers 21 x up to Ultra HD / 7 x in 8K Transition Keyer (Stinger/DVE) 4 Stinger, 4 DVE . Total Number of Layers 28 x up to Ultra HD / 7 x in 8K Pattern Generators 21 x up to Ultra HD / 9 x in 8K Color Generators 2 DVE with 3D Borders & Drop Shadow 4 x up to Ultra HD / 1 x in 8K Control Panel Front fascia emergency switching, software or optional hardware panel. Routable Windows 64 x up to Ultra HD / 16 x in 8K Tally Red for program and green for preview indication. Windows Source Labels Yes Multi View Monitoring Multi View Monitoring 4 x 16 Multi View pattern options for up to 64 total views. Multi View Video Standard Select HD, Ultra HD or 8K. Media Player Media Players 4 x up to Ultra HD / 1 x in 8K Channels Fill and key for each media player. Media Pool Still Image Capacity 64 x up to Ultra HD / 24 x in 8K with fill and key. Media Pool Clip Capacity 4 x up to Ultra HD / 2 x in 8K with fill and key. Media Player Clip Length in 720 HD 3200 frames. Media Player Clip Length in 1080 HD 1600 frames. Media Player Clip Length in Ultra HD 400 frames. Media Player Clip Length in 8K 100 frames. Media Pool Still Image Format PNG, TGA, BMP, GIF, JPEG and TIFF. Media Pool Video File Format TGA Sequence. Media Pool Audio File Format WAV, MP3 and AIFF. Display Interface Minimum monitor resolution of 1366 x 768. Front panel Built in HD LCD monitor for video, 42 LED buttons for setup and emergency switching, 8 source buttons, 4 transition buttons, 6 talkback selection and mix buttons, menu control knob and set button, front panel lock button. Processing Processing Delay < 7 lines in up to Ultra HD / in 10 lines in 8K Audio Mixer 156 Channel mixer Selectable On/Off/Audio-Follow-Video. Level and Peak metering. Master gain control. 6 band parametric EQ, Dynamics including Expander, Gate, Compressor and Limiter. Down Conversion None Software Control Panel Included ATEM Software Control Panel included free for Mac 10.13 High Sierra, Mac 10.14 Mojave or later and Windows 8.1 64-bit or Windows 10 64-bit. Software Updates Using USB 2.0 connection directly connected to Mac OS or Windows computers. Includes ATEM Setup Utility. Configuration Set via ATEM Software Control Panel, excluding ATEM chassis IP address which is set via the ATEM Setup Utility connected via USB to chassis. Operating Systems Mac icon Mac 10.14 Mojave, Mac 10.15 Catalina or later. Windows Icon Windows 8.1 64-bit or Windows 10 64-bit. Power Requirements Power Supply 2 x Internal 100 - 240 AC. Power Usage 300W Physical Specifications ATEM Constellation 8K Physical Installation Physical Installation 2 Rack Unit Size. Environmental Specifications Operating Temperature 0° to 40° C (32° to 104° F) Storage Temperature -20° to 60° C (-4° to 140° F) Relative Humidity 0% to 90% non-condensing What's Included ATEM Constellation 8K SD card with software and manual

Get everything you need for cameras in live production with a single converter! Connect your camera’s SDI or HDMI outputs for conversion to optical fiber, while your switcher program feed can be fed back via optical fiber for camera monitoring. ATEM Camera Converter includes an internal battery, talkback, tally, and microphone inputs!

The ATEM Camera Control Panel provides independent controls for up to 4 URSA Mini, URSA Broadcast, Blackmagic Studio and Micro Studio cameras from a single control panel. You get iris control, shutter speed, white balance, master gain, pedestal, RGB controls for white and black, and more. Connections Ethernet 2 x 10/100/1000 BaseT with loop output for additional control panels or computers. Software Updates 1 x USB-C for firmware updates. ATEM Camera Control Panel Product Specifics LCD Menu Displays 4 Camera Number Display Green off air, red on air. Setup White and black balance setup. 3 Axis Joystick 4 Preview Button 4 Iris Control Auto Iris On, Coarse control. Panel Active Protects settings. Software Software Applications ATEM Software Control Panel. Operating Systems Mac icon Mac 10.14 Mojave, Mac 10.15 Catalina or later. Windows Icon Windows 8.1 or Windows 10. Power Requirements Input Voltage 1 x Internal 100 - 240V AC. DC Power 12-30V 3A. Redundant Power Yes Power Usage 30W Physical Specifications ATEM Camera Control Panel Environmental Specifications Operating Temperature 0° to 40° C (32° to 104° F) Storage Temperature -20° to 60° C (-4° to 140° F) Relative Humidity Up to 95% What's Included ATEM Camera Control Panel

The new ATEM 2 M/E Production Studio 4K lets you produce broadcast quality live multi camera production in SD, HD or amazing Ultra HD! Featuring 20 inputs with built in re-synchronizers so you can connect the widest range of video sources such as cameras, disk recorders and computers for incredible live music, sport and more! ATEM 2 M/E Production Studio 4K has advanced broadcast features such as chroma key, customizable transitions, upstream and downstream keyers, DVE, Super Source, audio mixer, 2 x multi views, media pool and more! You also get 6G-SDI and HDMI 4K connections and 6 auxiliary outputs for the most advanced live production switching!

6G optical fiber module that works in SD, HD and Ultra HD for adding optical fiber to your Mini Converter Optical Fiber 12G.

3G optical fiber module that works in SD and HD for adding optical fiber to your Mini Converter Optical Fiber 12G.

12G optical fiber module that works in SD, HD and Ultra HD for adding optical fiber to your Mini Converter Optical Fiber 12G.

A remarkably small, portable hardware control panel, DaVinci Resolve Micro Panel has 3 high resolution weighted trackballs, 12 control knobs for essential tools, 18 dedicated navigation and transport keys, and more!
