Input / Output
Transmitter
HDMI 1.3 input ×1
HDMI 1.3 loop output x1
Receiver
HDMI 1.3 Primary output ×1
HDMI 1.3 Secondary output x1
Micro USB video capture output x1
Video Formats
HDMI
1080p60, 1080p59.94, 1080p50
1080p23.98, 1080p24; 1080p25, 1080p29.97, 1080p30;
1080psf23.98, 1080psf24
1080i60, 1080i59.94, 1080i50;
720p60, 720p59.94, 720p50
USB
1080p60, 1080p59.94, 1080p50
1080p23.98, 1080p24; 1080p25, 1080p29.97, 1080p30;
720p60, 720p59.94, 720p50
Wireless
Frequency
5.17GHz-5.69GHz and 5.75GHz-5.83GHz
RF Modules
OFDM 16QAM, 64QAM, QPSK, BPSK
RF Power
50mW
Transmission Distance
500 feet / 150 meters (Line of sight)
General
Input voltage
Transmitter DC 7-17V
Receiver DC 7-17V
Power Consumption
Transmitter 7.5W
Receiver 7W
Dimension(w/o antenna)
Transmitter 114.18×69.55×28 (mm)
Receiver 114.18×69.55×28 (mm)
Net weight
Transmitter 180.8g
Receiver 181.2g; With package 1.05kg
Working Temperature
0°C -+40°C
