Input / Output
Transmitter
3G/HD-SDI input×1, loop output ×1
HDMI 1.3 input×1
Receiver
3G/HD-SDI output×1
Video Formats
SDI
1080p60, 1080p59.94, 1080p50
1080p23.98, 1080p24; 1080p25, 1080p29.97, 1080p30;
1080psf23.98, 1080psf24
1080i60, 1080i59.94, 1080i50;
720p60, 720p59.94, 720p50
HDMI
1080p60, 1080p59.94, 1080p50
1080p23.98, 1080p24; 1080p25, 1080p29.97, 1080p30;
1080psf23.98, 1080psf24
1080i60, 1080i59.94, 1080i50;
720p60, 720p59.94, 720p50
Wireless
Frequency
5.17GHz-5.69GHz and 5.75GHz-5.83GHz
RF Modules
OFDM 16QAM, 64QAM, QPSK, BPSK
RF Power
128mW
Transmission Distance
10000 feet / 3000 meters (Line of sight)
General
Input voltage
Transmitter DC 7-34V
Reveiver DC 7-34V
Power Consumption
Transmitter 9W
Reveiver 9W
Dimension(w/o antenna)
Transmitter 66×106.5×24.7 (mm)
Reveiver 304.7×304.7×42.5 (mm)
Net weight
Transmitter 286g
Reveiver 2300g
Working Temperature
0°C -+40°C
