Mini SC1221 HDMI to Dual 3G-SDI Pocket-Size Broadcast Converter
Product Highlights
HDMI Type-A Input
Two 3G/HD/SD-SDI Outputs
Supports up to 1080p60 Resolution
Works 24/7 without Lag/Delay
Micro-USB Port for Power
AC Power Adapter Included
Can Be Connected to Power Banks, Etc.
LED Power Indicator
Mounting Bracket Included
AV Matrix SC1221 specs
Input
1 x HDMI type-A
Output
2 x 3G/HD/SD-SDI
HDMI Format Support
1080p at 50/59.94/60 fps
1080p at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 24/25/30/59.94/60 fps
576i at 50 fps
480i at 60 fps
HDMI Color Space
RGB 4:4:4, YUV 4:4:4, YUV 4:2:2
SDI Format Support
1080p at 50/59.94/60 fps
1080psf at 23.98/24/25/29.97/30 fps
1080p at 23.98/24/25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 24/25/30/50/59.94/60 fps
625i at 50 fps
525i at 59.94 fps
SDI Compliance
SMPTE 292M/SMPTE 259M/SMPTE 424M
SDI Color Space
YUV 4:2:2
Power Port
1 x micro-USB
Power Consumption
2 W
Voltage Range
3.3 – 5 V
Operating Temperature
-4 to 140°F (-20 to 60°C)
Storage Temperature
-22 to 158°F (-30 to 70°C)
Relative Humidity
0 to 90% non-condensing
Dimensions
2.9 x 1.6 x 0.9″ (7.4 x 4.1 x 2.3 cm)
PACKAGING INFO
Package Weight
0.8 lb
Box Dimensions (LxWxH)
4.7 x 3.3 x 3.1″
